Tell us about your application, and a PAVE engineer will get back to you with a rapid-turnaround quote. Whether you have a fully defined spec or are early in the design process, we can help.
For quotes, please include your operating conditions: pressure, temperatures, voltage, amperage, and type of gas or fluid being sealed, along with any size requirements.
Pressure and vacuum electrical and fiber optic hermetic bulkhead seal solutions for various temperature ranges not to exceed -200°C or up to 150°C or 200°C.
PAVE-Seal® feedthroughs have fixed wire leads sealed permanently through the bulkhead with no disconnect. PAVE-Mate® connectors add a mating plug on one or both sides so you can disconnect without disturbing the seal. Use PAVE-Seal® for a permanent passthrough; use PAVE-Mate® when you need repeated connect/disconnect access.
The standard factory test is 80 psi nitrogen with no visible bubble. High-vacuum helium testing to 10⁻⁸ cc/sec is standard on vacuum-rated designs. Helium mass spectrometer testing to 4 x 10⁻¹⁰ cc/sec is available on request.
Standard designs are factory-tested to 80 psi. Most designs can be tested to several hundred psi on request, and select configurations are rated to 10,000+ psi. Vacuum ratings reach 10⁻⁸ Torr for UHV applications.
Yes. PAVE’s proprietary epoxy seals through virtually any insulation, including PTFE, ETFE, PVC, polyimide (Kapton), silicone, and rubber. If you have a non-standard wire, submit your spec and a PAVE engineer will confirm compatibility.
In-stock Quick Ship designs typically ship within 2 to 4 weeks from receipt of a valid purchase order. Call +1 (937) 890-1100 x102 to place an order by phone. Credit cards accepted.
Call +1 (937) 890-1100 x103 or submit your spec online. A PAVE engineer will review your application and recommend the right solution at no charge.
